Quick Setup Guide

NS-L7HTV-10A TV

Step 1 Getting to know your TV and connecting your devices

Check out the front, side, and back panels to familiarize yourself with button controls and connection options.

Connect your devices using the diagram below as a guide. Press INPUT on your remote control to switch between devices.

Congratulations on your purchase of a high-quality

Insignia product. Your TV is designed for reliable and

trouble-free performance. Use this guide for initial

setup of your TV. See your User Guide for more

information on using your TV.

Package contents

• Remote control with battery

• AC adapter

• Vehicle adapter

• AV cable

• User Guide

• Quick Setup Guide

Volume

Adjust the volume.

Service port

Do not use.

VIDEO IN

Connect a standard

video device to this jack.

PHONE1 and 2 jacks

Connect a pair of

headphones to these jacks.

DC IN 9V jack

Connect the AC

adapter to this jack.

Power On/Charge indicator

Displays the power status.

When the TV is on, the indicator

is green. When the battery is

charging, the indicator is orange.

Power switch

Antenna jack

In TV mode, connect an antenna, cable TV, or

satellite TV to this jack. In radio mode, connect

the supplied antenna to scan for radio stations.

Note: The supplied antenna will be attached

with the portable TV when you receive the

product. The antenna is detachable. If you

want to connect an external antenna, you can

detach the antenna and connect other

external antenna.

Frame Stand

Open up the frame stand and

use it for supporting your TV.

Vehicle adapter

Remote control

AV cable

AC adapter

1 2
